Plate Shearing Machines

Get a Price/Quote

Plate Shearing Machines Specification

Type
Plate Shearing Machine

Material
Mild Steel (Body), High Carbon Steel (Blades)

Capacity
Varies by model (typically 6mm to 32mm sheet thickness)

Computerized
No

CNC Or Not
No

Control System
Hydraulic/electric control panel

Cutting Size
Upto 3200 mm length (can vary with model)

Cutting Thickness
Up to 32 mm (varies by model)

Cutting Width
1250 mm to 3200 mm (model dependent)

Blade Material
High Carbon High Chromium Steel

Voltage
415 V, 3 phase, 50 Hz

Power
7.5 HP to 25 HP (depends on model)

Dimension (L*W*H)
Customized as per model, approx. 4200x1800x1800 mm

Weight
Approx. 4 to 8 tons (depends on capacity/model)

Color
Blue & White (as shown in image)

About Plate Shearing Machines

We are a trader of Plate Shearing Machines

With our main mission of customer satisfaction with superior quality Shearing and Cutting Machines we always deliver items on time with the very competitive prices.

We Can Manufacture and Supply Various sizes of Plate Shearing Machines

Technical Specifications:

Uses	Flat Cutting up to 75 mm
Body	M.S. Prime Plate Fabricated
Welding	MIG Welding used for Machine Fabrication Dully Grind and Machined
Stress Relieve	Body of Machine Duly Stress Relieved
Crank	EN-Series Forged Steel
Slide	Forged Steel
Bearings	Imported Anti Friction Roller Bearing
Gears and Pinion	EN-Series Forged Steel
Flywheel	Graded Cast Iron
Pulley	Graded Cast Iron
Bush	Bronze
Blades	1 Set Fitted in Machine
Operation	Mechanical

Precision Shearing for Diverse Metals

These plate shearing machines are meticulously engineered to cut a wide range of materials, including mild steel, stainless steel, and various alloy sheets. With blade materials crafted from high carbon and high chromium steel, they deliver clean, accurate cuts up to 32 mm thick and lengths up to 3200 mm. The advanced hold down system ensures consistent precision and sheet stability during every operation.

Ease of Operation and Enhanced Safety

Operation is straightforward, utilizing foot pedals and push buttons for efficient control. Operator safety is prioritized with standard features such as finger guards and emergency stop switches. Depending on the model, machines are equipped with either manual or automatic lubrication systems, ensuring long-term performance and low maintenance requirements.

Robust Construction and Customizable Capacities

Manufactured with a sturdy mild steel frame, these machines offer durability and stability even during heavy-duty shearing tasks. Available in a range of capacities (6 mm up to 32 mm thick sheets, widths from 1250 mm to 3200 mm), and customizable dimensions to meet varied industrial needs, these machines are an ideal asset for metalworking facilities and workshops.

FAQs of Plate Shearing Machines:

Q: How does the hydraulic hold down system help during the shearing process?

A: The hydraulic hold down clamps secure the sheet firmly in place during cutting, minimizing movement or shifting. This ensures a precise, clean cut and enhances operator safety by preventing the material from slipping or misaligning during the process.

Q: What materials can be cut using this plate shearing machine?

A: This machine is engineered to cut mild steel, stainless steel, and a variety of alloy sheets or plates. Its robust blades made from high carbon, high chromium steel ensure effective cutting across a broad range of materials and thicknesses, up to 32 mm depending on the specific model.

Q: When should I choose manual versus motorized back gauge operation?

A: A manual back gauge is ideal for jobs requiring occasional adjustments or lower production volumes. Choose a motorized back gauge for frequent, precise, or repetitive shearing tasks to increase efficiency and accuracy, especially in higher volume industrial settings.

Q: Where are these plate shearing machines typically used?

A: These machines are widely utilized in metal fabrication facilities, heavy engineering workshops, and industries dealing with sheet metal processing, such as construction, automotive, and manufacturing sectors across India and globally.

Q: What safety features are included to protect operators during use?

A: Standard safety features include a durable finger guard to prevent accidental contact with the cutting blade and an emergency stop switch, allowing operators to quickly halt the machine in case of any hazardous situation.

Q: How does the lubrication system benefit machine performance?

A: Lubrication, whether automatic or manual, reduces friction and wear on moving components, ensuring smooth operation and prolonging the machines lifespan. Proper lubrication also helps maintain consistent cutting quality by minimizing blade and mechanism deterioration.

Q: What are the benefits of choosing a plate shearing machine with a hydraulic/electric control panel?

A: Hydraulic/electric control panels offer precise adjustment, stable operation, and easy monitoring of machine functions. This enhances cutting accuracy, improves operator convenience, and boosts overall productivity by providing reliable, user-friendly controls.
